Product Detail
Drywall Steel Frame
产品详情
Transport Package: 002


Steel structure /Steel metal frame/Steel channel

Product Description

1. hot dipped galvanized steel coil

2. high zinc coating: 60-275g can support, good protect quality for rustproof waterproof and fireproof.

3. certificate: CE, ISO , GB and strict production-lines , control quality and package.

4. different surface Technical treatment, dots, soooth, folded, line...

Advantage and feature:

1.Light weight, good strength, cauterization resistance and water resistance

2.Matching magnesium fire-proof board, gypsum board and many other walll and ceiling board

3.Moisture-proof, shock-resistance, environment-friendly and so on.

4.Easy and fast for install, time-saving

5. We can supply you the products based on your specific requirements


( High Quality Light Steel Keels for Drywall System/ Galvanized Metal Studs/ Tracks/ Steel Profile)

Item

Thickness

Height

Width

Length

Metal Stud

(C Stud)

0.4 / 0.45 / 0.5 / 0.6 mm

35 mm

50 mm

3000 mm

0.4 / 0.5 / 0.6 mm

40 mm

3000 mm

0.5 / 0.6 mm

50 mm

3000 mm

0.4 / 0.5 / 0.6 mm

35 mm

65 mm

3000 mm

0.4 / 0.5 / 0.6 mm

35 mm

70 mm

3000 mm

0.4 / 0.5 / 0.6 mm

40 mm

70 mm

3000 mm

0.4 / 0.45 / 0.5 mm

35 mm

75 mm

3000 mm

0.45 / 0.5 / 0.6 mm

45 mm

75 mm

3000 mm

0.5 / 0.6 / 0.8 mm

50 mm

75 mm

3000 mm

0.5 / 0.6 / 0.8 / 1.0 mm

50 mm

100 mm

3000 mm

0.8 / 1.0 mm

50 mm

120 mm

3000 mm

Metal Track

(U Track)

0.4 / 0.5/ 0.6 mm

30 mm

50 mm

3000 mm

0.4 / 0.45 / 0.5/ 0.6 mm

40 mm

3000 mm

0.4 / 0.5 / 0.6 mm

30 mm

65 mm

3000 mm

0.4 / 0.5 / 0.6 mm

30 mm

70 mm

3000 mm

0.4 / 0.5 / 0.6 mm

35 mm

3000 mm

0.4 / 0.45 / 0.5 mm

25 mm

75 mm

3000 mm

0.45 / 0.5 / 0.6 mm

35 mm

75 mm

3000 mm

0.5 / 0.6 / 0.8 mm

40 mm

75 mm

3000 mm

0.5 / 0.6 / 0.8 / 1.0 mm

40 mm

100 mm

3000 mm

0.8 / 1.0 mm

40 mm

120 mm

3000 mm

Furring Channel

0.4 / 0.45 / 0.5 mm

22 mm

35 mm

3000 mm

Main Channel

(Main Runner)

0.6 / 0.7 / 0.8 / 1.0 / 1.2 mm

10 mm

38 mm

3000 mm

0.5 / 0.8 / 1.0 / 1.2 mm

12 mm

3000 mm

0.6 / 0.7 / 0.8 / 1.0 / 1.2 mm

14 mm

50 mm

3000 mm

0.8 / 1.0 / 1.2 mm

15 mm

3000 mm

0.8 / 1.0 / 1.2 mm

27 mm

60 mm

3000 mm

Cross Channel

(Cross Runner)

0.35 / 0.4 / 0.45 / 0.5 / 0.6 / 0.7 / 0.8 mm

19 mm

50 mm

3000 mm

0.4 / 0.45 / 0.5 / 0.6 mm

27 mm

60 mm

3000 mm

Suspended Bar

0.6 / 0.7 / 0.8 / 1.0 mm

25 mm

20 mm

3000 mm

0.6 / 0.7 / 0.8 / 1.0 mm

28 mm

20 mm

3000 mm

0.6 / 0.7 / 0.8 / 1.0 mm

32 mm

20 mm

3000 mm

Wall Angle

(L Channel)

0.4 / 0.45 / 0.5 mm

25 mm

25 mm

3000 mm

0.6 mm

30 mm

30 mm

3000 mm

0.45 / 0.5 mm

32 mm

32 mm

3000 mm

Corner Bead

(Edge Bead)

0.4 / 0.45 / 0.5 mm

25 mm

25 mm

3000 mm

0.45 mm

30 mm

30 mm

3000 mm
